Stand Alone Mode
Spirometry test: FVC, VC, MVV, PRE/POST Bronchodilator comparison with a wide range of selectable parameters.
Paedriatric Incentive for Spirometry
Fast and silent built-in printer with customizable printout format.
Colour screen Touchscreen 7 inches TFT display.
Database up to 10,000 Spirometry tests or 900 hours of Oximetry recording coupled with powerful and flexible search services.
Optional function available: Oximeter with adult or paediatric finger probe.
Long life Rechargeable Battery.
Available with both DISPOSABLE or REUSABLE turbine flowmeters.
PC based mode, using WinspiroPRO®®
Bluetooth® 2.1 and USB Connectivity Wireless or via cable Real-Time test directly on your PC.
Winspiro PRO® PC software provides Real-Time Flow/Volume and Volume/Time curves with PRE/POST Bronchodilator comparison on your PC. Includes free online updates.
Paediatric Incentive for Spirometry with a wide choice of pictures and animations.
Spirometry test after drug administration
Bronchodilator Reversibility, Bronchial Challenge with FEV1-response curve with protocols for both Methacholine and Mannitol.
Quanjer 2012-GLI Predicted values with LLN and Z-score
Patient Trend Charts for easy follow-up
Search engine for instant access to database. Wide choice of communication protocols for integration with EMR.
1 WinspiroPRO CD
1 USB Cable
1 Miniflowmeter with cable
1 Power Supply/Battery Charger
1 roll of Thermal Paper
1 nose clip
1 carrying case
1 users manual
3 Years Warranty & Customer Support
Measured Parameters (PC Based and Stand Alone)
FVC, FEV1, FEV1/FVC, FEV1/VC, PEF, FEF25, FEF50, FEF75, FEF25–75, FEF75–85, Lung Age, Extrapolated Volume, FET, Time to PEF, FEV0.5, FEV0.5/FVC, FEV0.75, FEV0.75/FVC, FEV2, FEV2/FVC, FEV3, FEV3/FVC, FEV6, FEV1/ FEV6, FEV1/PEF, FEV1/FEV0.5, FIVC, FIV1, FIV1/FIVC, PIF, FIF25, FIF50, FIF75, FEF50/FIF50, VC, IVC, IC, ERV, IRV, Rf, VE, VT, tI, tE, VT/tI, tE/tTOT, MVV (measured), MVV (calculated).
Oxymetry parameters (Optional)
%SpO2 and Pulse Rate (Min, Max, Average), Test duration, Total SpO2 Events, T90% (SpO2 time ≤89%), T89% (SpO2 time ≤88%), T40 (Bradycardia duration with Pulse Rate <40 BPM), T120 (Tachycardia duration with Pulse Rate >120 BPM).
