GE T-2100 Treadmill – Stress Test Treadmill

GE T2100 Treadmill

Refurbished GE T2100 Treadmill

12 Months Parts and Labor Warranty

Option-Extended Warranty Available

The T2100 treadmill’s extra-long, 60-inch surface provides an extra margin of safety for patients. Its zero start feature slowly builds up speed for safe and smooth operation. And it can be slowed to a gradual stop, or stopped immediately with the standard emergency stop button. Full front and side handrails are also standard on the T2100 treadmill. With fewer moving parts than other treadmills, the T2100 treadmill delivers extremely smooth, quiet operation that facilitates accurate blood pressure measurements even at high workloads. Thanks to digital microprocessor control, its settings never need to be calibrated. And a 450-pound weight capacity and speed range of 0-13.5 miles per hour set the T2100 treadmill apart from other devices.

Performance OF GE T2100 TREADMILL

• Maximum Rated Load: 182 kg (450 lbs.)
• Drive Motor: 3.0 HP, brushless, DC motor
• Elevation Motor: 0.13 HP
• Belt Speed Range: 0.0 to 22.5 km/hr (0 to 13.5 mph) at 60 Hz, continuously variable, zero mph start-up
• Belt Speed Acceleration/Deceleration: Approximately 0.8 km/sec (0.5 mph/sec)
• Elevation Range: 0.0 to 25.0% grade, continuously variable
• Elevation Range Increase/Decrease: 1.14%/sec Manual Treadmill Controller (Optional): Functions: On, Off, Up, Down, Fast, Slow, Automatic Protocol Selection, Elapsed Time, Distance Traveled
• Automatic Protocols: 15 exercise and 15 rehabilitation (includes Bruce, Naughton, Balke II, Ellestad, Low Performance)
• Maximum Leakage Current: 100 A, chassis to ground Interface: RS-232 service port, 9600 baud (VT 100 or equivalent)
• RS-422 serial port, 9600 baud (CASE 12/15, MAX-1, MAC VU, and CENTRA Stress Systems)

Physical Specifications

Weight: 181.4 kg (400 lb)

Walking Area: 45.7 cm x 152.4 cm (18 in x 60 in)

Floor Space Required: 73.7 cm x 195.6 cm (29 in x 77 in)

Walking Surface Height: 14.0 cm (5.5 in)

Handrail Height Above Walking Surface: Front: 101.6 cm (40 in)

Side: Maximum 88.9 cm (35 in) descending at 5 angle to 81.3 cm (32 in)

Power/Environmental Specifications

Power Requirements: 200 to 240 VAC, 60 Hz, single phase, 20 A, NEMA 6-20 R wall socket (dedicated circuit recommended)

Power Consumption: 1540 watts

Operating Conditions:

Ambient temperature: 10C to 35C (50F to 95F)

Relative humidity: 20% to 90%

Storage Conditions:

Temperature range: -18C to 49C (0F to 120F)

Relative humidity: 20% to 90%
