GE Vivid 7 Ultrasound

GE Vivid 7 Ultrasound

$10,900.00 $9,800.00

Reconditioned GE Vivid 7 Ultrasound System

Call Us Today! 800.333.9111

GE Vivid 7 has Service Contracts and Extended Warranties available
Please inquire for applications and probes of each unit.

Cardiovascular Ultrasound System

With advanced features that provide you real-time 4D volume high-resolution image acquisition.
Tissue Synchronization Imaging (TSI)
Create flexible dynamic 4D models with quantitative measurements.


1-Year Parts and Labor Warranty

We also offer Technical Support by Phone or thru Remote Control.

Product Description

 GE Vivid 7 Ultrasound

GE Vivid 7 Ultrasound System Specifications:

  • Foot Print – USA (HxWxD) 54.1-62” x25.2” x 35.4”
  • Weight 419 lbs
  • Foot Print – Metric (HxWxD) 137.5157.5cm x 64cmx90cm

Console Design

  • 2D Frame Rate (probe dependent) up to 600 fps up to 500fps
  • Color Frame Rate (probe dependent) up to 100fps
  • Display Depth – up to 30cm 0-30 cm
  • Selectable Dynamic Range
  • Adjustable Transmit Focus
  • 3 Transducer Ports (3 active, 1 non imaging)

           User Interface

  • Easy to learn user interface with intelligent keyboard
  • Front panel with application specific rotaries and push buttons for primary controls
  • Application specific secondary controls available through slide bars operated by a four way rocker
  • Slide pot TGC curve with eight pots
  • Overall gain for 2D-mode Active mode Depth and Zoom Span on dedicated rotaries
  • Digital harvesting of images and loops into image clipboard
  • Patient Browser Screen for registration of demographic data and quick review of image clipboard contents
  • Fully programmable user presets for probe/application default settings
  • Standby function for fast bootup
  • Plug & Scan (option) allows up to 15 min Standby without power connection

Ergonomics                                                         Imaging Modes

Floating keyboard with lifting                         2D

Swivel and in/out keyboard                             M-Mode

Displacement. Backlit keyboard


Free Technical Support Call Us Today!

GE Vivid 7 Ultrasound

We have also EKG machines, Stress Test System, and ECG cables for Ge vivid 7 Ultrasound
